金屬絲平紋編織密紋網
金屬絲平紋編織密紋網
材質:不銹鋼絲、鎳絲、黃銅絲編織:金屬絲編織密紋網中緯絲聚密排列,有平紋編織密紋網、斜紋編織密紋網、竹花編織密紋網、反差編織密紋網。性能:采用不銹鋼絲編織而成。是經向、緯向絲徑和密度有較大反差,因而網子厚度和過濾精度及使用壽命比方孔網有較明顯的提高,它的過濾精度是方孔網布無法實現的。用途:主要用于氣體、液體過濾和其它介質分離,應用于航天、石油、化工等行業 。Material: Stainless Steel Wire , Nickel Wire , Brass WireWeaving : While the warp wires remain straight , the weft wires are plain woven as close as possible against each other which forming a dense strong material with twisting passageways . Plain weave dense wire mesh , twill weave dense wire mesh , bamboo weaving dense wire mesh and contrast woven dense wire mesh .Characteristic : Using the high quality stainless steel wire woven . Due to the warp , weft wire diameter and density have the greater contrast ,thus the net thickness ,filtration accuracy and the service life has been significantly improved. Its filtration accuracy can not be achieved by a square hole mesh .Main applications : Widely used for gas , liquid filter and other medium separation. Applied in aerospace ,petroleum and chemical 型號規格名義孔徑尺寸μm有效截面率%網重Kg/m2網厚mm對應舊標準網號MPW23118×740/0.063×0.0362321.50.380.135465MPW23100×1200/0.063×0.02337.60.270.109400MPW3280×400/0.125×0.0633216.60.770.251315MPW3570×340/0.125×0.083513.20.860.285280 ⅠMPW3665×770/0.10×0.0363637.10.430.172256MPW3770×390/0.112×0.0713716.30.740.254280 ⅡMPW3780×620/0.10×0.04529.80.530.19315MPW3877×560/0.14×0.053827.50.740.24300MPW3960×270/0.14×0.103911.21.030.34240MPW4080×700/0.125×0.044038.10.600.205315MPW4160×300/0.14×0.094114.10.960.32240MPW4265×400/0.125×0.0714219.10.780.267256MPW3070×930/0.10×0.033036.20.390.16280MPW5050×270/0.14×0.105015.20.980.34200MPW5160×500/0.14×0.0565134.10.700.252240MPW5550×280/0.16×0.095520.00.980.34200MPW5645×250/0.16×0.1125615.21.110.384180MPW6340×200/0.18×0.1256315.41.240.43160MPW6935×170/0.224×0.166912.81.620.544140MPW7435×190/0.224×0.147416.81.470.504MPW7730×140/0.315×0.207711.42.210.715120MPW8230×150/0.25×0.188213.51.790.61MPW9228×150/0.28×0.189215.91.870.64110MPW9724×110/0.355×0.259711.32.600.85594MPW10025×140/0.28×0.2010015.21.960.68100MPW11522×120/0.315×0.22411515.52.200.76390MPW12620×110/0.355×0.2512615.32.470.855MPW13020×160/0.25×0.1613028.91.560.5779MPW13320×140/0.315×0.2013321.51.970.715MPW14516×120/0.28×0.22414519.20.72863MPW15517.2×120/0.355×0.22415522.42.190.80368MPW16016×100/0.40×0.2816017.72.700.9660MPW17314×76/0.45×0.35517314.33.331.16MPW17714×110/0.355×0.2517722.22.280.85555MPW18214×100/0.40×0.2818220.32.620.96MPW19212.7×76/0.45×0.35519215.93.261.1650MPW21112×64/0.56×0.4021116.03.891.3647MPW21112×86/0.45×0.31520.92.931.08MPW24810×76/0.50×0.35524821.83.241.2140MPW24910×90/0.45×0.2824929.22.571.01MPW2758×85/0.45×0.31527527.32.731.0831MPW2968.5×60/0.63×0.4529620.34.161.5332MPW3108×45/0.80×0.6031015.55.702.0031MPW3197.2×44/0.71×0.6331914.25.551.9728MPW3477×40/0.90×0.7134714.36.652.3227
價格合理
品質優良
種類齊全
品質服務

24小時咨詢熱線:

139-3734-5906

全國服務熱線

139-3734-5906

新鄉市中南金屬網有限公司

聯系人:韓經理

電話:13937345906

郵箱:xxznjsw@163.com

地址:河南省新鄉市新東產業集聚區道清路12號

材質:不銹鋼絲、鎳絲、黃銅絲
編織:金屬絲編織密紋網中緯絲聚密排列,有平紋編織密紋網、斜紋編織密紋網、竹花編織密紋網、反差編織密紋網。
性能:采用不銹鋼絲編織而成。是經向、緯向絲徑和密度有較大反差,因而網子厚度和過濾精度及使用壽命比方孔網有較明顯的提高,它的過濾精度是方孔網布無法實現的。
用途:主要用于氣體、液體過濾和其它介質分離,應用于航天、石油、化工等行業 。


Material: Stainless Steel Wire , Nickel Wire , Brass Wire
Weaving : While the warp wires remain straight , the weft wires are plain woven as close as possible against each other which forming a dense strong material with twisting passageways . Plain weave dense wire mesh , twill weave dense wire mesh , bamboo weaving dense wire mesh and contrast woven dense wire mesh .
Characteristic : Using the high quality stainless steel wire woven . Due to the warp , weft wire diameter and density have the greater contrast ,thus the net thickness ,filtration accuracy and the service life has been significantly improved. Its filtration accuracy can not be achieved by a square hole mesh .
Main applications : Widely used for gas , liquid filter and other medium separation. Applied in aerospace ,petroleum and chemical


型號

規格

名義孔徑尺寸μm

有效截面率%

網重Kg/m2

網厚mm

對應舊標準網號

MPW23

118×740/0.063×0.036

23

21.5

0.38

0.135

465

MPW23

100×1200/0.063×0.023

37.6

0.27

0.109

400

MPW32

80×400/0.125×0.063

32

16.6

0.77

0.251

315

MPW35

70×340/0.125×0.08

35

13.2

0.86

0.285

280 Ⅰ

MPW36

65×770/0.10×0.036

36

37.1

0.43

0.172

256

MPW37

70×390/0.112×0.071

37

16.3

0.74

0.254

280 Ⅱ

MPW37

80×620/0.10×0.045

29.8

0.53

0.19

315

MPW38

77×560/0.14×0.05

38

27.5

0.74

0.24

300

MPW39

60×270/0.14×0.10

39

11.2

1.03

0.34

240

MPW40

80×700/0.125×0.04

40

38.1

0.60

0.205

315

MPW41

60×300/0.14×0.09

41

14.1

0.96

0.32

240

MPW42

65×400/0.125×0.071

42

19.1

0.78

0.267

256

MPW30

70×930/0.10×0.03

30

36.2

0.39

0.16

280

MPW50

50×270/0.14×0.10

50

15.2

0.98

0.34

200

MPW51

60×500/0.14×0.056

51

34.1

0.70

0.252

240

MPW55

50×280/0.16×0.09

55

20.0

0.98

0.34

200

MPW56

45×250/0.16×0.112

56

15.2

1.11

0.384

180

MPW63

40×200/0.18×0.125

63

15.4

1.24

0.43

160

MPW69

35×170/0.224×0.16

69

12.8

1.62

0.544

140

MPW74

35×190/0.224×0.14

74

16.8

1.47

0.504

MPW77

30×140/0.315×0.20

77

11.4

2.21

0.715

120

MPW82

30×150/0.25×0.18

82

13.5

1.79

0.61

MPW92

28×150/0.28×0.18

92

15.9

1.87

0.64

110

MPW97

24×110/0.355×0.25

97

11.3

2.60

0.855

94

MPW100

25×140/0.28×0.20

100

15.2

1.96

0.68

100

MPW115

22×120/0.315×0.224

115

15.5

2.20

0.763

90

MPW126

20×110/0.355×0.25

126

15.3

2.47

0.855

MPW130

20×160/0.25×0.16

130

28.9

1.56

0.57

79

MPW133

20×140/0.315×0.20

133

21.5

1.97

0.715

MPW145

16×120/0.28×0.224

145

19.2

0.728

63

MPW155

17.2×120/0.355×0.224

155

22.4

2.19

0.803

68

MPW160

16×100/0.40×0.28

160

17.7

2.70

0.96

60

MPW173

14×76/0.45×0.355

173

14.3

3.33

1.16

MPW177

14×110/0.355×0.25

177

22.2

2.28

0.855

55

MPW182

14×100/0.40×0.28

182

20.3

2.62

0.96

MPW192

12.7×76/0.45×0.355

192

15.9

3.26

1.16

50

MPW211

12×64/0.56×0.40

211

16.0

3.89

1.36

47

MPW211

12×86/0.45×0.315

20.9

2.93

1.08

MPW248

10×76/0.50×0.355

248

21.8

3.24

1.21

40

MPW249

10×90/0.45×0.28

249

29.2

2.57

1.01

MPW275

8×85/0.45×0.315

275

27.3

2.73

1.08

31

MPW296

8.5×60/0.63×0.45

296

20.3

4.16

1.53

32

MPW310

8×45/0.80×0.60

310

15.5

5.70

2.00

31

MPW319

7.2×44/0.71×0.63

319

14.2

5.55

1.97

28

MPW347

7×40/0.90×0.71

347

14.3

6.65

2.32

27
